Research

Facilities

복사냉각 측정 시스템
  • 장비명복사냉각 측정 시스템
  • 모델/제조사복사냉각장비+ 일사계
  • 위치C-4
  • 담당자이용준
  • 주요성능Thermocouple K-type*4, 히터 35W*1, Sample stage 75 x 75, 100 x 100, 전력측정 프로그램 수정 중
Thermal conductivity measurement
  • 장비명Thermal conductivity measurement
  • 모델/제조사자체 제작
  • 위치B-B1
  • 담당자홍동표
  • 주요성능Self heating method, Au plated Cu electrode, 20V, 8A PS, IR camera (T860) + Research max software, Transient/ Steady state, 전도성 박막, 섬유 측정 가능
Mist-CVD
  • 장비명Mist-CVD
  • 모델/제조사자체 제작
  • 위치B-5
  • 담당자이학지
  • 주요성능온도 범위 : 0 ~ 800 ℃, Carrier Gas : 0 ~ 50 LPM, Dilution Gas : 0 ~ 50 LPM, Frequency : 1.7 MHz
Spin Coater
  • 장비명Spin Coater
  • 모델/제조사ACE-200
  • 위치B-5
  • 담당자이은정
  • 주요성능Wafer size(Max.): 6 in (15.24cm), Rotation speed: 0 to 50 ~ 8,000 rpm, Acceleration: 1~ 3,000 R.P.M/sec, Step: 100 step, Memory storage: 100 program, Accuracy: ± 1 R.P.M
DC power Analyzer
  • 장비명DC power Analyzer
  • 모델/제조사N6705A
  • 위치B-5
  • 담당자송준용
  • 주요성능Function generator 사인파, 사각파 등 임의 파형 가능, module : 20 V, 3 A 내에서 CV or CC mode 입력 가능
Digitizer
  • 장비명Digitizer
  • 모델/제조사Axon Digidata 1440a Digitizer
  • 위치B-7
  • 담당자방용빈
  • 주요성능16 independent analog input channels at up to 250 kHz each, four independent 16-bit analog outputs, eight digital output lines
Shear mixer
  • 장비명Shear mixer
  • 모델/제조사L5M-A / Silverson
  • 위치C-316
  • 담당자양현서
  • 주요성능Power : 1hp (≈ 750W), Capacity: 12 L, RPM : ~ 10,000, AC 230 V, Emulsor/Square Hole High Shear Screen, Slotted Disintegrating Head 보유
Homogenizer
  • 장비명Homogenizer
  • 모델/제조사HT-120DX/DAIHAN
  • 위치C-316
  • 담당자양현서
  • 주요성능Power : AC 230V, 50 / 60Hz, RPM : 50 ~ 1,000, Chuck Grip Capa. Φmm: dia Φ 6~12mm Shafts, \
Disc Cutter
  • 장비명Disc Cutter
  • 모델/제조사Puncher
  • 위치C-316
  • 담당자이학지
  • 주요성능사용 가능 Disc size : 15 ø , 20 ø , 24ø
Freeze dryer
  • 장비명Freeze dryer
  • 모델/제조사MLB-9003/Mareuda
  • 위치C-316
  • 담당자이학지
  • 주요성능Capacity: 3 Kg/batch, Cold trap temp.: - 90℃, 전격: 220 V, 15 A, 기존 용기 600 ml : 2 ea / 900 ml : 2 ea / 1200 ml : 2 ea
Spray coating system
  • 장비명Spray coating system
  • 모델/제조사BBA-M001 +BBA-GP35 +BB-SBD002 / Beetle Bug
  • 위치C-316
  • 담당자고은서
  • 주요성능팬 사이즈 : 120 x 120 x 38mm, 팬 풍량 : 9m^3/min, 전력 : 220V / 60Hz, 노즐구경 : 0.3 mm , 도료컵 용량 : 7cc , 적정 사용 압력 : 1 ~ 2 bar
Sonication
  • 장비명Sonication
  • 모델/제조사Tip-Branson / VCX 750
  • 위치C-316
  • 담당자고은서
  • 주요성능초음파 출력 : 750W, 기본 Probe : 13 mm
Plasma Cleaner
  • 장비명Plasma Cleaner
  • 모델/제조사PDC-32G
  • 위치C-316
  • 담당자이용준
  • 주요성능Maximum RF power : 18W, Dry Air 및 N2 연결 가능
Thinky mixer
  • 장비명Thinky mixer
  • 모델/제조사AR-100 / THINKY Corporation
  • 위치D-411
  • 담당자박용열
  • 주요성능400-2000 rpm, 465 G, 50 ml / 100 g (net), 50 ml / 140 g (gross), 용기 부피 50% 이상 사용 제한, Max 30 min (rest time 0,5~1 h)
2032 coin cell Kit & Crimper
  • 장비명2032 coin cell Kit & Crimper
  • 모델/제조사HSMCC-P10 (Crimper) , WC-H125 (Punching tool) / wlcos
  • 위치C-411
  • 담당자박용열
  • 주요성능Φ 14, Φ 16, Φ 19 Punching 2032 assemble (Φ 20mm , t 3.2 mm), 정해진 키트 외 사용 주의
Atomic la<x>yer Depostion System (ALD)
  • 장비명Atomic layer Depostion System (ALD)
  • 모델/제조사자체 제작
  • 위치C-B105
  • 담당자조태웅
  • 주요성능Vacuum gauge : 1 mTorr ~ 1,000 Torr, Furnace Temp.: ~ 800℃, Line Temp.: ~ 250℃, Canister Temp.: ~ 250℃, MFC ~100 sccm (Canister), ~500 sccm (Purging), Max sample size : 2 x 2 cm
Digital Muffle Furnace
  • 장비명Digital Muffle Furnace
  • 모델/제조사FX-14 / DAIHAN Scientific
  • 위치C411B
  • 담당자이은정
  • 주요성능300 ℃~ 1000 ℃ (14 Lit.), Heating power: 4.0 kW , 전원: AC 120, 60Hz or AC 230V, 50/60Hz, Single phase, 800℃ 도달까지 20 min 소요, 내부 크기: 25cm*35cm*16cm
Amplifier
  • 장비명Amplifier
  • 모델/제조사Axopatch 200b moleculardevice
  • 위치B-7
  • 담당자방용빈
  • 주요성능 Holding potential range: ±1000 mV/ Holding current range: ± 200 nA /Output gain 0.5 ~ 500 mV/pA
Dynamic light scattering  (DLS)
  • 장비명Dynamic light scattering (DLS)
  • 모델/제조사Ex250 (external probe)/Nanotrac Wave
  • 위치C-316
  • 담당자강서영
  • 주요성능입도 범위: 0.3 ~ 10,000 nm /제타 전위: -200 ~ -200 mV /분자량 범위: 1 KDa ~ 20 MDa / Laser source: 반도체 laser 780 nm / Power: 3 mW nomial / Detection system: Silicon photodiode /Typical analysis time: 10 ~ 1,800 sec /220 V 50/60 Hz
Thermal evaporator
  • 장비명Thermal evaporator
  • 모델/제조사자체 제작
  • 위치C-B1
  • 담당자전영표
  • 주요성능2 evaporation sources for deposition with boat, crucible, and basket /Quick release removable substrate mounting plate, various types of substrate available/Highly accurate quartz crystal thickness monitor system
Sputtering system
  • 장비명Sputtering system
  • 모델/제조사자체 제작
  • 위치C-B1
  • 담당자전영표
  • 주요성능3” metal, dielectric (metal oxide) targets (DC and RF sputtering) /Rotational substrate mounting system /Dual technique deposition with e-beam deposition source
Electrospinning system
  • 장비명Electrospinning system
  • 모델/제조사자체 제작
  • 위치B-5
  • 담당자전옥성
  • 주요성능- Nanofiber, microporous non-woven fabric 제작 가능 - Power supply : Spellman CZE 1000R, Voltage : ~ 30kV, Current : ~ 300μA
Rotary evaporator
  • 장비명Rotary evaporator
  • 모델/제조사HS2005V-N/ HAHNSHIN S&T CO., LTD
  • 위치C-4
  • 담당자송준용
  • 주요성능Speed : 20 ~ 280 rpm
Cell tester
  • 장비명Cell tester
  • 모델/제조사WBCS3000/ WonAtech
  • 위치B-5
  • 담당자이학지
  • 주요성능Standard model/ 8 channel battery cycler/ Channel expandable up to 128 channels/ Voltage range : ±5 V/ Max. Current range : ±5 A@5 V (4 ranges)/ max. power per channel : 50 Watt
Scanning Ion-Conductance Microscopy (SICM)
  • 장비명Scanning Ion-Conductance Microscopy (SICM)
  • 모델/제조사NX-Bio/ park system
  • 위치B-7
  • 담당자방용빈
  • 주요성능both AFM and Scanning Ion Conductance Microscopy (SICM) are integrated with Inverted Optical Microscopy (IOM)
Gel Permeation Chromatography (GPC)
  • 장비명Gel Permeation Chromatography (GPC)
  • 모델/제조사Agilent 1260 Infinity Ⅱ/ Agilent
  • 위치B-7
  • 담당자송준용
  • 주요성능Auto sampler, Pressure range: < 600bar/ Temp. range: 4 ~ 40℃/ Flow rate: 0.05 ~ 5 ml per min/ Injection rate : 0.1 ~ 100 μL/ Refractive Index detector, up to 72Hz/ Column ① PLgel 5 μm mixed-C 300 x 7.5 mm ② Poreshell 120 EC-C18
Multi nozzle spinning system
  • 장비명Multi nozzle spinning system
  • 모델/제조사- / Chilsung Engineer
  • 위치B-7
  • 담당자전옥성
  • 주요성능system size : 1500 mm × 590 mm/ 3 step washing process: 1315 mm stainless steel bath, 3 washing bath : 1.5 L, RT/ drying temperature : ~ 100 ℃
Potentiostat
  • 장비명Potentiostat
  • 모델/제조사IviumStat.h standard/ Ivium
  • 위치B-5
  • 담당자전옥성
  • 주요성능 Scan range: ±5A/±10V Maximum applide voltage ±10V below 1A, and ±8V up to 5A/ Potentiostat Applied potential range ±10V, 0.02 mV res.(20bit)/ Galvanostat Potential ranges ±1mV, ±4mV, ±10mV, ±40mV, ±100mV, ±400mV, ±1V, ±4V, ±10V/ Impedance Analyser Dyn
Viscometer
  • 장비명Viscometer
  • 모델/제조사DV2T/ BROOKFIELD
  • 위치C-316
  • 담당자이용준
  • 주요성능Rotating speed: 0.1 ~ 200 rpm/ Temp range: -100 ~ 300 ℃
BET
  • 장비명BET
  • 모델/제조사BELSORP-mini Ⅱ / SOLETEK
  • 위치C-316
  • 담당자송준용
  • 주요성능Specific surface area : 0.01 m2/g or more (N2), Pore size distribution (diameter) : 0.35 ~ 500nm, Port : 2, Large volume Cell (4 cm3) (Standard cell : 1.8 cm3)
2-probe system
  • 장비명2-probe system
  • 모델/제조사Kelthley 6487/ Tektronix
  • 위치C-316
  • 담당자강서영
  • 주요성능Current Range: 2 nA – 20 mA/ Voltage: 200 uV – 1 mV/ W@Au Tip
Thermo Mechanical Analyzer (TMA)
  • 장비명Thermo Mechanical Analyzer (TMA)
  • 모델/제조사TMA7100/ HITACHI
  • 위치C-316
  • 담당자박용열
  • 주요성능Temp. range: RT~ 600 ℃/ Heating rate: 0.01~100 ℃/min/ Strain sensitivity: 0.01 um/ Max. Load : ± 5.8 N/ Load resolution: 9.8 uN/ Max. displacement: ± 5000 um/ Stroke speed range: 0.01~10^6 um/min
Universal Testing Machine (UTM)
  • 장비명Universal Testing Machine (UTM)
  • 모델/제조사T&DRF 티앤돌프 / TD-y012018
  • 위치C-316
  • 담당자박용열
  • 주요성능road cell – 1000 gf/3000 gf, road resolution 1/50000, Testing speed 0.01 ~ 500mm/min, Power Supply AC 220V, 50/60Hz
Scanning Electron Microscope (SEM)
  • 장비명Scanning Electron Microscope (SEM)
  • 모델/제조사SNE4500M / SEC
  • 위치C-316
  • 담당자강서영
  • 주요성능Max. res.: 5 nm/ Mag. range: 20 x ~ 100,000 x/Beam 1~30kV/Tilt 0~45 도/Max. sample size: ⏀80 mm × h35 mm/X, Y 40mm, Z 0~35mm/Rotator 360 도/Image shift ± 150 um
Polarized optical microscope
  • 장비명Polarized optical microscope
  • 모델/제조사BX51TRF/ OLYMPUS
  • 위치C-316
  • 담당자박용열
  • 주요성능Polarized Image/ Ocular lens (Eye piece): x 10 (1, 1.25, 1.6, 2 배)/ objective lens: x 10, x 50, x 100
High-Speed Centrifuge
  • 장비명High-Speed Centrifuge
  • 모델/제조사2236R/ LABOGENE
  • 위치C-316
  • 담당자양현서
  • 주요성능Power : 230V/50Hz (100V optional)/Max. rot. speed : 22,000 rpm (54,111 g)/ Capacity : 6 x 1,000 ml, 30 x 1.5 per 2.0 ml/ Temp. range : - 20℃ to 40℃/Time control: < 100hr, continuous
Rolling press
  • 장비명Rolling press
  • 모델/제조사MSK-HRP-MR100DC/ MTI
  • 위치C-316
  • 담당자박용열
  • 주요성능Sample area: 100 (dia.) x 100 (W) mm/ Rotating speed: 5 ~ 40 mm/s (0.3 ~ 2.4 M/min)
Hot Press
  • 장비명Hot Press
  • 모델/제조사PCH-600CG/Tianjin Pinchuang
  • 위치C-316
  • 담당자박용열
  • 주요성능Pressure range: 0 ~ 24 T (0 ~ 34 MPa)/Cylinder diameter: ⏀95 mm/ Temp. Range: RT ~ 500 ℃
Tube furnace
  • 장비명Tube furnace
  • 모델/제조사OTF-1200X/ MTI Corp.
  • 위치C-B105
  • 담당자이은정
  • 주요성능Quartz Tube, Max. temp.: 1100℃ (1200℃), Heating rate: 1 ℃/ min ~ 20 ℃/min, Inert Gas 사용 가능
Wet spinning system
  • 장비명Wet spinning system
  • 모델/제조사KdScientific / LEGATO 110
  • 위치C-316
  • 담당자이학지
  • 주요성능Adaptable syringe: 0.5µl ~ 60ml(Min~Max), Pumping rate: 1.28 pl/min (0.5 µl syr.)~88.28 ml/min (60 ml syr.), 100-240VAC : 50 / 60Hz, 50W, 0.5A 퓨즈
Box furnace
  • 장비명Box furnace
  • 모델/제조사S-BA1800/ HANTECH
  • 위치C-B105
  • 담당자이은정
  • 주요성능MAX 1600 ℃ (1700 ℃), H2 사용 X, 10 steps, 500 ℃ 미만 사용 제한, 승온속도 1 ℃/min ~ (승온속도 MIN, MAX 값은 확인 예정)
Wet hydrogen furnace
  • 장비명Wet hydrogen furnace
  • 모델/제조사ASTRO/ THERMOFISHER SCIENTIFIC
  • 위치C-B105
  • 담당자홍동표
  • 주요성능Temperature range: <1800℃/ Evironment: Ar, N2, H2/ Water cooling system installed
Centrifuge
  • 장비명Centrifuge
  • 모델/제조사X-30R/ BECKMAN COULTER
  • 위치C-B105
  • 담당자홍동표
  • 주요성능Max. rot. speed : 16000 rpm/ Max. capacity: 4 x 400 mL/ Temp. range: 2-40oC
3D microscope
  • 장비명3D microscope
  • 모델/제조사VMA-2520/ NIKON
  • 위치C-B105
  • 담당자홍동표
  • 주요성능Magnification: 0.35 ~ 3.5x/ Resolution: 0.1 um/ LED lighting stage
Field Emission Testing System
  • 장비명Field Emission Testing System
  • 모델/제조사- / -
  • 위치C-B105
  • 담당자홍동표
  • 주요성능< 5kV/ < low 10^-8 torr
Vector network analyzer
  • 장비명Vector network analyzer
  • 모델/제조사MS4644A/ Tektronics
  • 위치C-B105
  • 담당자홍동표
  • 주요성능Frequency range: 10 MHz-40 GHz
1GHz Oscilloscope
  • 장비명1GHz Oscilloscope
  • 모델/제조사TDS510413/ TEKTRONICS
  • 위치C-B105
  • 담당자홍동표
  • 주요성능< 1 GHz
15 kV Power supply
  • 장비명15 kV Power supply
  • 모델/제조사HV-PPS-15K/ 15 kW
  • 위치C-B105
  • 담당자홍동표
  • 주요성능Maximum volatge:15kV/ Maximum power: 15kW/ Pulse Operation
Inverter tig welder
  • 장비명Inverter tig welder
  • 모델/제조사TSI-300/TST-300T/ Taesang
  • 위치C-B105
  • 담당자Matlabjon
  • 주요성능Current range: 5-200 A/ Power range: 4.7 kW/ Frequency range: 2.5-250 Hz
Laser welder
  • 장비명Laser welder
  • 모델/제조사HLS-610E/ HBL
  • 위치C-B105
  • 담당자Matlabjon
  • 주요성능Rep. rate: 1-100 pps/ Pulse width: 80 us-20 ms/ Spot size: 15 mrad, 0.8 mm
Bake out station
  • 장비명Bake out station
  • 모델/제조사- / 신풍정공
  • 위치C-B105
  • 담당자Matlabjon
  • 주요성능1E^-8 torr
Magnetizer
  • 장비명Magnetizer
  • 모델/제조사US-6607SM/ LDJ Electronics, Inc.
  • 위치C-B105
  • 담당자Matlabjon
  • 주요성능7500 J/ 5-6 T/ Programmable/ Cycle time 11 s
